DESCRIPTION

STANDARD 235 MM CENTRE MACHINE

OPTIONAL 305 MM CENTRE MACHINE

80 MM SPINDLE
BORE MACHINE

Admit Between Centre Atul - 0 ( 5'.6" feet )
Atul - 0 ( 7'.0" feet )
Atul - 0 ( 9'.0" feet)
Atul - 0 ( 10'.0" feet )
Atul - 0 ( 12'.0" feet )
Atul - 0 ( 14'.0" feet )

Height of Centre over Flat Bed Ways
Maximum Swing over Bed
Maximum Swing over Cross Slide
Maximum Swing in Gap
Length of Gap in Front of Face Plate
Bed Type
Bed Width

500 mm
965 mm
1575 mm
1905 mm
2515 mm
3100 mm
235 mm
455 mm
255 mm
775 mm
200 mm
2V & 2 Flat
325 mm

-----
965 mm
1575 mm
1905 mm
2515 mm
3100 mm
305 mm
595 mm
395 mm
915 mm
200 mm
2V & 2 Flat
325 mm

Number of Spindle Speed
Range of Spindle Speed
Spindle Nose Dia
Spindle Bore
Spindle Threads
Spindle Morse Taper
Spindle Morse Taper with Adaptor
Nylon Flat Belt
Head Stock V-Belt

8
30 to 550 RPM
76.2 mm
52 mm
6 TPI
MT-6
MT-4
50 x 1900 mm
C-75

8
30 to 550 RPM
104.775 mm
80 mm
6 TPI
MT-6
MT-4
50 x 1900 mm
------

Cross Slide Dimensions
Cross Slide Travel
Compound Slide Travel
Tool Section

200 x 280 mm
250 mm
140 mm
25 x 25 mm

200 x 470 mm
350 mm
140 mm
25 x 25 mm

Spindle Diameter
Spindle Travel
Spindle Morse Taper

50 mm
180 mm
MT-4

Number of Threads Range in Metric
Number of Threads Range in Inch
Number of Pitch Range in Metric
Number of pitch Range in Inch
Lead Screw Diameter
Lead Screw Threads

13
19
1 to 6 PITCH
2 to 24 TPI
38 mm
4 TPI

Electric Motor (OPTIONAL)

3-HP

Standard Accessories	Optional Accessories
Set of change Gears Inch Center Adapter Dead centers - 2 Nos. Chuck Plate 200mm & 270mm Reversible Switch V - Belt ( B - 72 ) 2 Nos. Nylon Flat Belt Tool Post Key Motor Pulley Carriage Tray Oil can Screw Driver Spanners - 3 Nos. Spare Parts Book	Flame Hardened Bed 80mm Spindle Bore only in Flat Belt Bush type with height of centre 305mm Six Feed Gear Box Norton Gear Box Long Slide With Rear Tool Post Taper Turning Attachment Steady Rest Metric Gears Height of Center - 305mm with specifications

Note : In our constant effort to improve our machine, we reserve the right to change any of
the technical specifications without prior notice.
